Features:
Technical Specifications:
| Where to use | Home, Restaurant, Kitchen, School room, Shopping mall |
| FOR what Dimension | Size:Dia78*118mm*H158mm |
| Powers for choices: | 5w/7w/10w/12w/15w/20w/30w/35w/40w |
| Color | W/WW/Neutral |
| LED Type | COB,Sanan or other Chip for choices |
| Lumens | 70-80ml/w,1600ml for 20W |
| Material | Aluminium |
| Input Voltage | AC85-265V,50-60Hz |
| Environment Temperature | -20℃~ +44℃ |
| Color rate index | ≥70Ra |
| Carton size(For 20W)/Packing | 67cm*43cm*34cm/40pcs |
| Install Type | Track Rail |
| Full Size Sample Lead time: | As usual 3-7 working days |
| warranty time: | 2Years or 3Years |
| Items Nos. | Powers | Dimension | Light Source | Lumens |
| TSL-TL001-7W | 7W | Dia59*L98mm | COB | 490-560LM/W |
| TSL-TL001-10W | 10W | Dia59*L98mm | COB | 700-800LM/W |
| TSL-TL001-12W | 12W | Dia59*L98mm | COB | 840-960LM |
| TSL-TL001-15W | 15W | Dia78*L118mm | COB | 1050-1200LM |
| TSL-TL001-20W | 20W | Dia78*L118mm | COB | 1400-1600LM |
| TSL-TL001-30W | 30W | Dia89*L139mm | COB | 2100-2400LM |
| TSL-TL001-35W | 35W | Dia89*L139mm | COB | 2250-2800LM |
| TSL-TL001-40W | 40W | Dia89*L139mm | COB | 2800-3200LM |
